| Application |
| Application | decentralised controller; PROFIBUS DP gateway |
| Electrical data |
| Operating voltage [V] | 24 DC |
| Insulation rating [V] | 500 |
| Current consumption [mA] | < 500 |
| Max. current consumption from AS-i [mA] | 10 |
| Max. power consumption [VA] | 10 |
| Number of AS-i masters | 2 |
| Electrical separation | yes |
| Interfaces |
| Communication interface | RS232; PROFIBUS |
| PROFIBUS |
| Transmission standard | EN 50170 |
| Transmission rate | 12 MBaud |
| Protocol | Profibus DP |
| Usage type | data transmission |
| Addition | diagnostic function |
| RS232 |
| Number of R232 interfaces | 1 |
| Transmission rate | 9600…115200 Baud |
| Connector type | RJ11 |
| Usage type | programming |
| Addition | electrically isolated |
| Operating conditions |
| Ambient temperature [°C] | 0…60 |
| Storage temperature [°C] | -20…70 |
| Protection | IP 20 |
| AS-i classification |
| AS-i version | 2.1 + 3.0 |
| AS-i profile | M4 |
| AS-i certificate pending | yes |
| Mechanical data |
| Weight [g] | 561.5 |
| Housing | housing for DIN rail mounting |
| Materials | aluminium; steel sheet galvanised |
| Displays / operating elements |
| Display | | function | 3 x LED, red | | 3 x LED, green | | 3 x LED, yellow | | full graphic LCD display | |
| Remarks |
| Pack quantity | 1 pcs. |
